Key ideas in Designing Electronic Systems
- A divider's lower branch forms a parallel circuit with the downstream device's input impedance.
- Input impedance sags the output voltage unless it is at least 10 times the divider's resistance.
- High-impedance inputs need op-amp buffers or lower divider resistances to measure accurately.
- Standard 5V TTL inputs register any voltage above 2.0V as a valid logic HIGH.
- Direct 3.3V outputs can drive 5V TTL inputs, but 5V outputs can damage 3.3V CMOS inputs without shifters.
- 5V CMOS inputs require roughly 3.5V for HIGH, making level translation mandatory in that direction.
- Schmitt triggers use separate upper and lower thresholds (hysteresis) to prevent signal chatter.
- Level shifters safely translate signal voltages across incompatible power domains.
- Internal pull-ups bias high-impedance inputs to a known rail when left unconnected.
- CMOS inputs have gigohm-scale gate resistance and act like tiny, sensitive antennas when open.
- Floating inputs pick up stray capacitive coupling and toggle unpredictably between 0 and 1.
- Mechanical contacts physically bounce for 2 to 20 ms, generating multiple rapid edge transitions.
- An RC filter slows switch voltage transitions to smooth out contact chatter before logic stages.
- Software debouncing ignores repeated state changes during an initial settling delay window.
- Negative feedback drives the op-amp output so the difference between input pins stays at zero
- A grounded non-inverting terminal creates a virtual ground of 0V at the inverting pin
