Key ideas in Reading and Troubleshooting Circuits
- A normal grounded circuit reads ~120V hot-to-neutral and ~120V hot-to-ground.
- Zero volts hot-to-ground alongside normal hot-to-neutral shows an open ground path.
- Reversed hot and neutral would read 120V neutral-to-ground and 0V hot-to-ground.
- Parallel AC conductors induce stray capacitive voltage onto disconnected wires.
- Standard digital meters have 10-megohm impedance, displaying harmless ghost voltages.
- A low-impedance (LoZ) mode puts a small load across leads, shunting ghost voltage to 0V.
- A loose terminal or corroded splice passes full voltage when no current is drawn.
- Drawing load current through resistance causes significant upstream voltage drop.
- Standard branch circuits should typically drop less than 3% to 5% under rated load.
- An open neutral breaks the return path, turning off all connected loads downstream.
- Connected appliances pass full line voltage through their filaments to the neutral wire.
- Downstream neutral screws become a lethal shock hazard without tripping the breaker.
- Disconnecting the supply breaker is always the mandatory starting procedure.
- A multimeter must be proved operational on a known live source before zero-testing.
- Applying continuity mode to live voltage blows internal meter fuses or causes flashover.
- Split-phase legs are 180 degrees out of phase from a center-tapped transformer.
